Elevating Series Downdraft Grossing Station (DHE SERIES)

APZEM Elevating series downdraft
Grossing Station were designed to provide
Sturdy, customizable and affordable
workstation for medium to large Labs. The
Elite Elevating series workstation comes
with higher suction capacity, ergonomically
designed and additional height adjustable
features that assists in high productivity
grossing as well as protects you from
inhaling harmful Formalin fumes.

Technical Specifications –ELEVATING DOWNDRAFT GROSSING STATION ((DHE SERIES)

Specification	Details
Model	DH6000E
MOC (Material of Construction)	SS304 (Standard) / SS316 (Optional)
Ventilation	Downdraft
Dimension	1800 mm (Length) × 905 mm (Width) × 1885 mm (Height)
Work Surface	900 mm height from the ground; height can be increased up to 1200 mm
Sink	790 mm × 660 mm × 310 mm (Depth)
Filters	Water-washable polyester pre-filters, with optional custom-designed filter
Electrical	220–240 VAC, 50/60 Hz, 1 Phase; 110 V supplied on request
Plumbing – Water Connection	1/2″ industrial-grade flexible hose supplied for hot and cold water connection
Plumbing – Drain Connection	1 1/2″ drain hose (waste disposal)
Waste Disposal	Optional
Waste Disposal Unit	0.55 HP high-capacity waste disposal unit
Exhaust Air Capacity	1800 CMH
Perforated Working Area	800 mm (Length) × 750 mm (Width)
Exhaust Duct Diameter	200 mm diameter
